單柱式三工位換網器Single cylinder type screen changer with three working positions

結構規格：StructureSpecifications

整體圓柱式三工位結構，帶穩壓機構，換網時三網兩兩交替同時工作，連續不斷，超強密封。

Integrated cylinder type structure with 3 working position, equipped with pressure-stabilizingstructure, 3 alternate screens will combine as 2 screen pack and working simultaneously with continuous and super sealing.

應用范圍：Applications

適合大型吹膜（共擠）、土工膜、復合管材、彩復、淋膜流延等產品。

Large-scale film blow(co-extrusion), geomembrane, composite pipes, color reproduction, membrane casting and etc.

性能特點：Features

非常規加工及熱處理方式，主體耐壓60MPa，在大型螺旋機頭或口模間隙極小的“T”型模頭上使用。

Unconventional process and heat-treatment, the pressuretolerance of the main body is 60MPa, For large screw machine head and extremely tiny T extrusion with die extremely tiny tap

設有穩壓機構及 “接力式”排氣系統, 換網過程穩定、連續、不斷料

Equipped with pressure-stabilizingstructure and “relay topology” exhaust   system. Ensuring the screen changing process steady, uninterrupted and nonstop feeding.

自動潤滑系統，超長壽命，無需維修。

Auto lubrication system, super long working life, no maintenance is needed.

技術參數Technical Parameters：
